Weinas_90 Series Non‑Thermal‑Break Aluminium Casement Window

90 Series Non‑Thermal‑Break Aluminium Casement Window‑Cost‑effective non‑thermal‑break casement window built for global budget residential and export projects.

  • 1.4mm aluminium profile delivers good structural strength for economical export solution
  • Non‑thermal‑break aluminium window system offers diverse opening configurations, insect screen is not supplied as standard
  • Multiple opening variants available: fixed window, casement window, inward‑opening window, top‑hung window, inward tilt‑and‑turn window, outward awning window, window‑style door upon request
  • Standard glazing adopts 5mm single clear glass
  • Bespoke sizes & textured powder‑coat colour selections available, direct factory supply with competitive price and long‑standing warranty coverage
Categories , , , Tags , , ,

Description

Overview

Weinas 90 Series Non‑Thermal Break Aluminium Casement Window is a cost‑effective window solution developed for worldwide budget‑focused residential buildings, simple apartments and export orders. It adopts mature non‑thermal‑break aluminium alloy frame construction. Standard 5mm single clear glass meets basic daylighting and ventilation requirements.  Practical appearance and solid basic performance make this window widely used for overseas economical construction projects.

Robust & Stable Structure

The whole window frame uses 1.4‑mm‑thick high‑purity aluminium alloy profile. Wider frame section brings improved overall rigidity and deformation‑resisting performance for general‑purpose residential usage.

Flexible Glazing

This window comes with standard 5mm single clear glass to satisfy basic safety and daylighting needs for economical projects. Alternative glass configurations are negotiable on special project request, all glass conforms to international glass safety standards.

Operation Types

Available opening modes: fixed window, casement window, inward‑opening window, top‑hung window, inward‑tilt‑and‑turn window, outward top‑hung window. Window‑style door can be made upon request.

Hardware & Security

Standard functional hardware is factory pre‑installed for smooth opening & closing. Factory pre‑assembly and inspection ensure acceptable air‑tightness and water‑tightness for general‑purpose buildings. Insect screen is excluded from standard package.

Colour & Customization

Textured powder‑coat surface finish provides good UV‑resistance and anti‑corrosion property for exterior application. Standard colours: Textured Grey, Textured Coffee. Custom sizes are available according to project design requirements.

Direct Factory Supply, Custom Production

All aluminium windows are custom‑manufactured based on project drawings and site measurements. As direct manufacturer, Weinas offers favourable factory price with export‑reinforced packaging for sea and land transportation. Distributors, contractors and project buyers enjoy full‑cycle service from drawing confirmation to shipment, together with long‑term warranty and after‑sales support.

Item Details
Profile Thickness 1.4mm Aluminium Profile Thickness
Standard Glazing 5mm Single Clear Glass
Hardware Standard Functional Hardware
Surface Finish Textured Powder Coating
Operation Type Fixed / Casement / Inward‑Opening / Top‑Hung / Inward‑Tilt‑and‑Turn / Outward Top‑Hung, Window‑Style Door available
Standard Colour Textured Grey, Textured Coffee
Insect Screen Not Included

Contact us today with your opening dimensions. Our engineering team will prepare window layout drawings and provide a detailed quotation as soon as possible.
